Altium CircuitMaker is a free PCB design tool.Įvery subscription level comes with Altium Support, which includes support tickets, a chat function, documentation center, access to Altium community forums, and more.Įasy to use.
An annual license costs $3,850 per seat for the standard plan or $4,845 (per seat per year) for the pro plan. Altium Designer starts at $325/month (for one seat) with a 15-day free trial. Altium Designer is a paid version that combines schematic, ECAD libraries, rules and constraints, BoM, supply chain management, ECO processes, and world-class PCB layouts.Īltium’s most popular product is Altium Designer, but other Altium products include:Īs detailed on Altium’s website, the software program has a variety of features and capabilities, including:Īltium offers two subscription plans - standard and pro.
Altium CircuitMaker and Altium Designer - CircuitMaker is a free program that provides you with up to 16 signals and 16 plane layers plus no restrictions to the PCB dimensions.
Ability to create detailed revision commentsĪltium, a global software company that provides PCB design tools and resources, calls itself as “a global market leader with the #1 PCB software tool in use today.”. It was developed jointly by Dassault and Altium Limited and launched in 2016, which means it’s a relatively new PCB design tool compared with some of the others on the market. Solidworks PCB (formerly PCBWorks) was a PCB design tool from Dassault Systèmes, a French software company. It’s in the realm of Altium Designer but has more functionality and is geared toward more complex PCB designs. PADS - This is a top choice when it comes to PCB software. The schematic editor doesn’t have any paywalls, and the company explains that “every effort is made to hide the complexity of advanced design features so that KiCad remains approachable by new and inexperienced users.” KiCad EDA - This free software boasts a 3D viewer so that you can review your design from multiple perspectives. If you download EAGLE for free, you will work with a limited version that includes two schematic sheets, two signal layers, and an 80 cm2 board area. EAGLE (Easily Applicable Graphical Layout Editor) - This industry staple is a free software option that is compatible with paid design software. OrCAD is essentially a trimmed-down version of Allegro PCB. OrCAD is the most popular schematic capture tool in the Cadence suite, while Allegro is Cadence’s flagship PCB layout tool. OrCAD and Allegro - These popular design tools are produced by the same company, Cadence.
We’ll explore Altium, one of the most popular software programs on the market, but here are some additional options to consider:
